Temassız Termal Kameralı El Tipi Isı Ölçer
Temassız Termal Kameralı El Tipi Isı Ölçer
|
Model Parameter |
DS-2TP31B-3AUF |
|
|
Handheld Thermography Camera |
||
|
|
Image sensor |
Uncooled Focal Plane Arrays |
|
|
Max. Resolution |
160 × 120 |
|
|
Pixel Pitch |
17μm |
|
|
Response waveband |
8μm to 14μm |
|
|
NETD |
< 40mK (@ 25 °C,F#=1.0) |
|
|
Field of View |
37.2° × 50 ° |
|
|
Focal length |
3.1 mm |
|
Thermal Module |
IFOV (mrad) |
5.48 mrad |
|
|
Min. Focus Length |
≥ 150 mm |
|
|
Aperture |
F 1.1 |
|
|
Monitor |
320 × 240 resolution 2.4’’ LCD display |
|
Image Display |
Palettes |
Black hot, White hot, Rainbow, Ironbow 3 thermometry points: Max. Temperature; Min. |
|
|
Rules |
Temperature; Center Temperature |
|
Thermography |
Thermographic Range |
30°C to 45 °C |
|
|
Thermographic Accuracy |
±0.5 °C |
|
|
Battery Type |
Rechargeable Lithium Battery |
|
|
Battery Operating Time |
8 hours continuous running |
|
|
Storage |
Replaceable memory card (default 8G, support up to 128G storage) |
|
|
Photo |
Thermal image |
|
Battery |
Video |
N.A. |
|
|
Language |
English |
|
|
Power |
3.7 V DC/0.4 A |
|
|
Power Consumption |
Less than 1.2 W |
|
|
Hardware Interface |
micro USB |
|
|
Working Temperature |
-10 °C to 50 °C (14 °F to 122 °F) |
|
|
Protection level |
IP54 |
|
|
Drop Test Height |
2 m (6.56 feet) |
|
|
Dimension |
196 mm × 117 mm × 59 mm (7.7 ″ × 4.6 ″ × 2.3 ″) |
|
General |
Weight |
Approx. less than 350 g (0.77 lb) |
